These mills are made of full cast iron casting fitted with bearings in dust proof housing and well aligned shaft to fit moving stones. The stationary stone fitted on mill side cover. The mill has two outlet and fineness control device and safety momentary disengaging device and safety spring. The mill feeding from grain hopper through feeder fitted with eccentric to feed food grains constantly into the mills. This mill can be used commercially and agricultural purpose.
S.No. | Size (mm.) | Motor( H.P.) | RPM | Flour Output ( Kg/h) |
1. | 600 | 20 | 700 | 350-500 |
2. | 750 | 40 | 600 | 500-700 |
These Mill are made of Heavy Duty angle and fitted with mill stone. The bearings are fitted in dust proof upper & lower bearing housing. These are very popular in rural area of India & useful for multigrain grinding including Wheat, Maize, Bajra (Barley) and spices etc.
S.No. |
Size (mm.) |
Motor (H.P.) |
RPM |
Flour Output (Kg/h) |
1. |
250 |
1 H.P. |
500 |
15-20 |
2. |
300 |
1.5H.P. |
600 |
25-30 |
3. |
350 |
2 H.P. |
600 |
35-40 |
4 |
400 |
3 H.P. |
600 |
50-70 |
5. |
450 |
5 H.P. |
600 |
75-100 |
‘EMERALD’ mark Indian horizontal type grinding mills are constructed with mild steel plates mounted on strong channel / angle structure, bright steel shaft, dust - proof bearings with oil seal and superior ‘EMERALD’ mark millstones are fitted to ensure longer life. The lower stone rotates on tapered shaft - end aligned automatically with key - end provided at the shaft. Upper stationery stone rests on adjustable strong bolts. The system for fixing the stationery stone incorporates the great advantage that is possible to align the stone to each other without recutting or redressing. A mild steel sheet strip is provided around the grinding stones tightened with nut - bolts to enable the operator at any time to check the alignment. A hand wheel regulates the grinding according to the degree of fineness desired. The ‘EMERALD’ horizontal type mills are available from size 250mm (10”) to 1200mm (48”).
Sr. No. |
Size (mm.) |
Motor (H.P.) |
RPM |
Flour Output (Kg/h) |
1. | 400 | 5.0 | 600 | 100 |
2. | 450 | 5.0 | 600 | 125 |
3. | 500 | 7.5 | 600 | 175 |
4 | 600 | 15 | 550 | 250 |
5 | 750 | 25 | 500 | 350 |
These Mills are made of graded cast iron, fitted with extra hard emery mill stone and useful for Hostel, Hotel and all grocery shops.
Technical Specifications:
Stone Size | 8"/20 cm | 10"/25 cm | 12"/30 cm | 14"/35 cm |
Model | VCT 20 CM | VCT 25 CM | VCT 30 CM | VCT 35 CM |
H.P. | 1 | 1.5 | 2 | 3 |
Power Consumption (Unit / hr) | 1.2 | 1.5 | 1.5 | 2.2 |
Capacity / Output (kg / hr) | 20-30 | 30-40 | 40-60 | 60-80 |
Weight (Kg) | 30 | 35 | 55 | 65 |
Voltage | 220-240 V | |||
Electricity Connection | Single Phase | |||
R.P.M. pulley | 550 | 600 | ||
Warranty | 6 Months | |||
Material | Mild Steel & Cast Iron | |||
Feature | Chakki are available with third pedestal & 3 bearings |
These mills are made of graded Cast Iron body with Heavy Duty fitments and base frame. This mill is improved Danish Model with three bearings and one additional pedestal to rest shaft and perform excellent services. Mill stone of thickness 75 X 75 mm are being used in these flour mills.
S.No. | Size( m m ) | Motor( H.P.) | RPM | Flour Output( Kg/h) |
1. | 300 | 3 | 600 | 75-100 |
2. | 350 | 3 | 600 | 100-130 |
3. | 400 | 7.5 | 600 | 150-200 |
4. | 500 | 15 | 550 | 200-300 |
5. | 600 | 20 | 550 | 300-400 |
6. | 750 | 40 | 550 | 500-700 |
Made of Graded Cast Iron body with heavy duty fitments and base frame, one additional pedestal to rest shaft and perform excellent services. Mill stone of thickness up to 125 X 125 mm can be fitted in these mills that ensures longer life of stone.
S.No. | Size( mm.) | Motor( H.P.) | RPM | Flour Output (Kg/h) |
1. | 400 | 10 | 650 | 150 |
2. | 450 | 15 | 600 | 250 |
3. | 500 | 20 | 600 | 300 |
Made of cast Iron plate, foundation and the mill body are covered by SS sheet. The mill is popular in central part of India with their unique features. The millstone of thickness 125 X 125 mm is being used in these mills.
S.No. | Size ( mm.) | Motor ( H.P.) | RPM | Flour Output ( Kg/h) |
1. | 350 | 5 H.P. | 600 | 100-130 |
2. | 400 | 10 H.P. | 500 | 150-200 |
3. | 450 | 15 H.P. | 550 | 200-250 |
Key Features: A Unique Flour mill for Home use, Suitable for all kind of Food Grains and Spices.
Simple Mechanism |
Simple Mechanism Manual Operating. |
Complete with Flour Collection Tray |
No any extra Tray Require for Flour Collection. |
Easy to operate |
No technical Knowledge requires for operate the Chakki. |
No Electricity Required |
No Electricity required for operate the Chakki. |
Good exerciser for Women |
The Chakki is Good exerciser for Women at the Home. |
Technical Specifications:
S.No. | Model | Operation | Output (Kg/h) | Gross Weight |
1 | MS 35cm | Manual | 2-3 Kg | 36 Kg |
2 | SS 35cm-natural | Manual | 2-3 Kg | 36 Kg |
3 | MS 40cm | Manual | 3-5 Kg | 48 Kg |
4 | SS 40cm-natural | Manual | 3-5 Kg | 48 Kg |
Uses:-
You can grind Wheat, Besan, Rice, Bajra, Maize, Jowar, Barley, Millets, Lentils, Dhaniya, Haldi, Kali-Mirch, and all other grains and spices.
Output capacity as per grain/spice and fineness.
Made of cast iron body, is fitted with Heavy duty iron stand. The mill is fitted with bearings to ensure smooth running and grinding is done by reversible grinding plates, it is fitted with mesh control device to obtain fine flour output. The mill is being used for wet and dry food grain application and can grind all kind of grains.
S.N. | Size (mm.) | Motor ( H.P. ) | RPM | Flour Output (Kg/h) |
1. | 175 | 2 | 350 | 50-70 |
2. | 250 | 5 | 450 | 100-150 |
3. | 300 | 7.5 | 450 | 150-200 |
The construction is of graded cast iron Beam and the mill Casing mounted on angle iron stand: 6mm thick base plate, Bright steel shaft with Bearings Steel gear pinion. The beam is moving in self lubricated non-ferrous metal bush. The mill can crush all varieties of oil seeds and be operated with electric motor as well as diesel engine.
Technical Specifications:
Product | Daily Capacity | RPM | HP REQ | HOPPER Capacity | Nett Wt. | Gross Wt. | Measurement |
Rotary Oil Mill | 100/125 Kg | 30 | 5 | 12 Kg | 415 Kg | 525 Kg | 2 x 1 x 1 Mtrs. |
Rotary Mini Oil Mill | 50/60 Kg | 30 | 3 | 3 Kg | 160 Kg | 180 Kg | 1 x .5 x .5 Mtrs. |
